Paper Egg Tray Making Machine

Paper egg tray making machine is employed to make different paper egg trays. It recycles useless waste paper and makes valuable egg trays in a short time. Therefore, investors benefit from this project quickly. Nowadays, more countries have demand for this hot machine. Look at the following parameters to choose the right one.

Projects and Customer Visits about Beston Pulp Egg Tray Making Machine

More than 30 countries have installed Beston paper tray forming machine, for example, Syria, Egypt, Algeria, India, Brazil, Chile, Zambia, Peru, Mali, Dominica, India, Ivory Coast, Senegal, the Philippines, Hungary. Moreover, some customers brought machines when they expanded their business. Beston are willing to offer more services to customers.

Exported Countries of Beston Egg Tray Machine
Exported Countries of Beston Egg Tray Machine
India Customer Visited Egg Tray Forming Machine
India Customer Visited Egg Tray Forming Machine
Egg Tray Moulding Machine in Dominica
Egg Tray Moulding Machine in Dominica
Good Feedback from Indian Customer - Pulp Egg Tray Making Machine
Good Feedback from Indian Customer
Pulp Egg Tray Machine Installed in Ivory Coast
Pulp Egg Tray Machine Installed in Ivory Coast

Select the Right Types of Beston Egg Tray Machines

Manual Egg Tray Making Machine – Small Scale

Manual type has small capacity. Its capacity ranges from 1000-1500pics/h. Furthermore, it operates simply. It is suitable for these people who do small recycling business. Besides, the cost of matched drying system is also low.

Automatic Paper Egg Tray Machine – Medium or Large Scale

Beston has five models of automatic type, including semi-automatic models and fully automatic models. Each model has its suitable drying systems. Choose a suitable model according to capacity.

Model BTF-1-3 BTF-1-4 BTF-3-4 BTF-4-4 BTF-4-8 BTF-5-8 BTF-5-12
Production capacity (pieces/h) 1000 1500 2000 2500 3000-4000 4000-5000 5000-6000
Forming mould quantity 3 4 12 16 32 40 60
Total power 34kw 41.2kw 53.7kw 57kw 90kw 150kw 153kw
Electricity consumption (70% of the total power) 23.8kw·h 28.84kw·h 37.59kw·h 39.9kw·h 63kw·h 105kw·h 107.1kw·h
Labor force 3-5 4-6 4-6 4-6 5-7 5-7 5-7
Materials consumption Paper 85 102 170 212 298 425 459
Water 255kg/h 306kg/h 510kg/h 636kg/h 894kg/h 1275kg/h 1377kg/h
Fuel consumption Coal 50 60 83 104 125 208 208
Natural gas 22-32 26-36 37-47 46-56 56-66 92-103 92-103
Diesel 18-28 22-32 30-40 38-48 46-56 77-87 77-87
BTF-1-3
BTF-1-3 Paper Egg Tray Machine 1000pics/h

BTF-1-4
BTF-1-4 Paper Tray Making Machine 1500pics/h

BTF-3-4
BTF-3-4 Paper Tray Forming Machine 2000pics/h

BTF-4-4
BTF-4-4 Beston Paper Tray Machine 2500pics/h

BTF-4-8
BTF-4-8 Paper Egg Tray Making Machine 3000-4000pics/h

BTF-5-8
BTF-5-8 Pulp Egg Tray Making Machine 4000-5000pics/h

BTF-5-12
BTF-5-12 Beston Egg Tray Making Machine 5000-6000pics/h

What Raw Materials Paper Tray Machine Can Be Used for Making Trays?

Majority of paper waste can be applied to make paper trays, including books, magzine, cardboard, and other paper-made products. Make egg trays is one of the most economic ways to recycle waste. Firstly, every country has wide source to get waste paper at a low price. Secondly, using pulp egg tray making machine won’t bring pollution to the environment. Thus, just take this equipment to do your business right now.

Different Trays Beston Pulp Egg Tray Machine Made

Egg Tray
Egg Tray
12-hole Egg Carton
12-hole Egg Carton
Bottle Tray
Bottle Tray
Fruit Tray
Fruit Tray
Coffee Cup Tray
Coffee Cup Tray
Electrics Tray
Electrics Tray
Shoe Tray
Shoe Tray
Apple Tray
Apple Tray

Economical Drying Systems of Beston Egg Tray Forming Machine

Beston provides three drying systems to reduce the water of egg trays. When you don’t sure choose which one, send detailed message to us.

Drying System Description
Drying Under the Sun Put finished egg trays under the sun by trolley. Normally, when drying under the sun about 30℃, the whole drying process needs about 4 hours. When temperature reaches to 38-40℃, the process is shorted to 2-3 hours. However, it also relates to the wind speed, moisture content, and other factors. Because it needs manual labour force to move and transport, it is suitable for small egg tray production, like BTF-1-3 and BTF-1-4.
Semi-Automatic Drying System It is also called brick-trolley drying system. Put egg trays into trolley. Then workers push trolley into bricking system. The fuel for this system can be coal, diesel or natural gas. In this case, we recommend that investors who do small business choose this drying system.
Fully Automatic Drying System There are two methods, brick-drying conveyor and multi-layer metal drying system respectively. When you use coal as the fuel of multi-layer metal system, add a hot air stove to purify the fuel and prolong service life of this machine.
Drying Under the Sun
Drying Under the Sun – Small Scale Production

Brick Drying Conveyor
Brick Drying Conveyor – Small Scale Production

Semi-automatic Drying System
Semi-automatic Drying System – Small or Large Scale Production

Metal Drying System
Metal Drying System – Large Scale – Production

Comparasion of Four Dyring Systems

Building Cost drying under the sun < brick-trolley drying system < brick-conveyor drying system < metal drying system
Automation Level drying under the sun < brick-trolley drying system < brick-conveyor drying system = metal drying system
Factory Workshop Occupied drying under the sun > brick-trolley drying system > brick-conveyor drying system = metal drying system

Egg Tray Machine Video – Project in India

Estimate Egg Tray Machine Price

1. Cost for Egg Tray Moulding Machine and Drying System

Generally, larger the capacity of egg tray plant is, more money the machine cost. Besides, when you do this business, take factory workshop into consideration. The more info you provide to us, the more suitable plan we can offer for you, including detailed price list.

2. Cost of Raw Material and Energy

Firstly, the cost of raw materials is low. Secondly, water in egg tray making system is circle. Thirdly, different types of drying systems have different requirement for the fuel. You can select the most economical fuel on the basis of local area.

Contact Dependable Egg Tray Machine Manufacturers

1. Beston has own manufacturing plant and team. Every customer is able to come to factory and check Beston equipment.

2. Beston’ professional team controls every segment to guarantee customers’ right.

3. Besides project plan, we also offer customized plan and good after-sales service.

How to Make Egg Tray by Egg Tray Equipment

Pulp Making Line

Put waste paper into the hydraulic pulper. Under the power of water, the waste paper will be made into rough pulp.
Then the rough pulp will enter into homogenization pool. In homogenization pool, the pulp will be refined by the vibration screening machine. At the same time, the concentration of the pulp will be adjusted well. After adjusted, the pulp will flow into pulp supplying pool.

Egg Tray Forming Line

The finished pulp will be transported into forming machine by pulp pumper. Under the suction power of vacuum pumper, the pulp will be adsorbed up on molds to form egg tray. Under the blowing force of air compressor, the formed egg tray will be blowed off from molds to next process – drying line.

Egg Tray Drying Line

After drying, you can pack these egg trays by packing machine. The purpose of stacking egg trays is to save space and to reduce transportation cost.

If you want to produce egg box, you will need a hot press machine. After this step, the surface of egg box will be more smooth and more hard.


How to Make Egg Tray
How to Make Egg Tray by Beston Egg Tray Plant

All in all, egg tray making machine makes economic egg trays with less money. When you invest this machine, the right model and drying system will help you to make more profits. Besides regular paper trays, Beston offers customized service to help you make ideal trays. You can visit some projects videos on Youtube.
